UV Laser Marking 3w-20w Flying U Series
Adopted with superior green and UV laser, the material is more easily absorbed and the thermal diffusion of material can be reduced. The method of breaking molecular bonds could make pure black, no-touch and more clearly printing effect marking.
FARLEY LASERLAB AUTO: UV Laser Marking Machine
UV Laser Marking 3w-20w Flying U Series
Adopted with superior green and UV laser, the material is more easily absorbed and the thermal diffusion of material can be reduced. The method of breaking molecular bonds could make pure black, no-touch and more clearly printing effect marking.
It is widely used in electronic components, integrated circuits, hardware, automobile parts, plastics, precision equipments and many other fields.
UV Laser Marking Machine Flying U Series
Green/UV laser marker with low-thermal pure black marking, GMP/HACCP compliance, 24/7 operation and multi-industry applications.
Features:
Green & UV Laser Technology
Energy Efficient & Easy to Use
GMP & HACCP Compliant
Pure Black Non-Contact Marking
24/7 Continuous Operation
Low Thermal Diffusion
UV Laser Marking Machine – Technical Specifications
It is suitable for all kinds of pipes, plastic films, plastic bottle caps and other PPR, PVC, PE and other materials. It is widely used in food and beverage packaging, alcohol, dairy products, electronic components, medicine and medical devices, personal and home care products, tobacco, building materials, grain and oil seasoning products and other fields, and realizes the marking of graphics and words such as production validity date, batch number, shift, manufacturer name and logo.
| Flying ultraviolet series coding equipment | |||||
|---|---|---|---|---|---|
| Model | Flying 5U | flying 10U | Flying 15U | Flying 20U | |
| Mark parameters | Marking range | F=160mm/100mm×100mm (standard); F=210mm/140mm×140mm (optional); F=254mm/175mm×175mm (optional); F=300mm/220mm×220mm (optional) | |||
| Font type | Built-in standard fonts can be selected, and special fonts can be generated and edited. | ||||
| Support printing content | Text information, variable information, serial number, batch number, QR code, logo and graphic image | ||||
| Marking speed | ≤12000mm/s, the actual marking speed depends on the material | ||||
| Mark the minimum line width | 0.1mm (depering on the material) | ||||
| Laser wavelength | 335nm | ||||
| Power stability (average power) | ±5%rms | ||||
| Operating environment temperature | External ambient temperature 0-40℃ (32-105℉), ambient humidity 10%-90%, no condensation | ||||
| Communication interface | Network port, serial port, USB port | ||||
| System power supply | 1.0KW/AC220V/50Hz | 1.5KW /AC220V/50Hz | |||
| Product size | Mainframe size | 700mm(H)*330mm(L)*600mm(W) | |||
UV Laser Marking 3W-20W Flying U Series
- Flexible structure, the professional stand can be installed on the assembly line, easy adjustment;
- Professional industrial laser source, faster marking speed and consistent marking, high reliability, operated continuously in 24 hours, meet the demands of mass processing and production;
- High electro-optic conversion efficiency, low consumption, long life, save a lot of processing costs for customers;
- Friendly man-machine dialogue interface, easy operation, without bothering for the operators altering.
Short-wavelength high-quality ultraviolet laser focuses on the light spot smaller
Narrow pulse width laser has a short working time on materials.
The effect of heat impact is small, and the effect of meeting the standard is more beautiful.
It can realize the fine marking of special materials.
Samples Display
